Oh Wow Cycles™ Circuit Breaker MTN

Oh Wow Cycles™ Circuit Breaker MTN


The “big guy” of OH WOW CYCLES e-bikes. The CIRCUIT BREAKER is a heavy bike built for those who are after adventure and high performance. This is OH WOW CYCLES’ flagship e-bike intended for all types of riding from smooth, on-road cruises to intense trail biking.  You are assured of safety and reliability when you ride this e-bike. The CIRCUIT BREAKER is what you need to add more fun and excitement to your riding experience!


Flexible financing available through Synchrony

Technical Specifications

What makes Circuit Breaker Mtn the best E-bikes?

Electric System

Motor Bafang 750W rear hub motor
Controller Lishui 25A
PAS Sensor 0-5 levels
Charger 100V-240V 2A – Waterproof and quick connect
Battery 48V 15Ah Lithium-ion battery
Battery Range 20+ miles
Charging Time 4-6 hours
Display KingMeter SW Big LCD
Throttle Thumb throttle
Head light Yes
Taillight Yes

Main Components

Frame 6061 Aluminum alloy
Brake NUTT disc brake
Fender Aluminum alloy
Chain KMC, steel
Shift Lever Shimano 7 speed
Suspension MOZO suspension fork
Rim Aluminum alloy
Saddle ChiFan leather
Pedal Wellgo, Aluminum alloy
Stem Aluminum alloy
Fork MOZO suspension fork
Brake Lever Wuxing with power cut-off
Gear shifting ARD-FT35AD, Shimano 7 speed
Shifter ASLTX50R7CT, Shimano 7 speed
Spoke Stainless steel
Sprocket Prowheel, Aluminum alloy
Kickstand Aluminum alloy
Handlebar Aluminum alloy
Tools Included Yes
Front basket No
Rear Rack Aluminum alloy
Bell Included


Range 20 + miles
Loading Capacity 130 kgs
NW.: 31 kgs
Packing Size: 160*28*78 cm
GW 40 kgs


Tire Chaoyang 26″*4.0, Quick release front wheel
Frame Size
Handlebar Height 117 cm
Handlebar Reach
Seat Height 81-104 cm
Standover Height
Total Length 182 cm
Wheelbase 115 cm
Seat Tube Length 35 cm
Top Tube Length
Chainstay 152.4 cm
Handlebar Width 66 cm
Crank Length 17 cm
Seatpost Diameter 3.04 cm
Max Tire Width 10 cm


***Parts may very with availability***

Quick Info

What makes it special?


48V 750W

Bafang Hub Motor



Up to 20

Miles Per Charge


48V 15Ah

Lithium-Ion Battery


4-6 Hours

Charging Time


330 lbs

Payload Capacity


Blue/Black, Army Green, Gray
